Embrace the legacy and make your mark on history with the UB-Xa from Behringer. More than just a recreation of a classic synthesizer, we’ve made sure that the UB-Xa has all the bells, whistles and characteristics that came with the original, but it’s also filled to the brim with modern features such as velocity and after-touch, 512 user program memories and comprehensive MIDI implementation. This makes for a well-rounded synth that’ll make friends with anything in your setup.
Features:
- Analog polyphonic synthesizer and authentic reproduction of classic OB-Xa including original factory patches
- Vintage mode allows the selection of 8 synthesizer signatures including OB-Xa, OB-8 and more
- 16 voices with 2 VCOs per voice and oscillator sync mode
- The multi-timbral capability allows the splitting or layering of 2 different sounds
- VCOs and VCFs based on reproductions of original 3340 and 3320 semi-conductor designs
- Both VCOs generate sawtooth, triangle or square waveforms with variable pulse width
- Selectable dual-slope 12/24 dB analogue low-pass filter per voice with adjustable resonance
- 61 semi-weighted full-size keys featuring poly after-touch and velocity sensitivity
- Flexible 8-channel modulation matrix for dramatic expansion of sonic possibilities
- Dual-layer arpeggiator and sequencer with real-time sequence transpose
- Velocity and after-touch can be optionally used for more expressive performance
- 2 dedicated LFOs with 7 waveform shapes for modulation of pulse width, oscillator pitch and filter cutoff frequency
- 2 ADSR generators per voice for control of VCF and VCA
- Stereo VCA per voice to allow control over voice/layer panning
- 26 rotary controls give direct and real-time access to all important parameters
- High-quality LCD Display with encoder for rapid parameter editing
- Assignable preset recall switches for immediate program selection
- Spring-loaded pitch and assignable modulation paddles provide total hands-on performance
- 512 user program memories with a “compare and match” feature to quickly match all analogue controls to stored program values
- Fully servo-balanced outputs for the highest signal integrity
- CV/pedal inputs for connection to expression pedals and footswitches
- MIDI Polyphonic Expression (MPE) to enable multidimensional controllers and multiple parameters per note
- Comprehensive MIDI implementation (including NRPN/CC control of all parameters and bulk load/save)
Specifications:
- No. of Keys: 61 full-size keys with velocity and polyphonic aftertouch
- Number of voices: 16-voice bi-timbral
- Type: Analog
- Oscillators: 32
- LFO: 2
- VCF: 1 low pass, 2-pole or 4-pole, (12dB or 24dB/ oct slope), switchable
- Envelopes: VCA, VCF
- Connectivity: 5-pin DIN / 16 channels MIDI In/Out/Thru, USB 2.0 type B MIDI , 2x Main Output 1/4" TRS balanced max. 22 dBu, Headphones 1/4" TRS stereo max 25mW dBu, Foot pedals (Vibrato 1/4" TRS balanced) (Filter 1/4" TRS balanced), Foot Switches (Sustain1/4" Mono) (Program Advance 1/4" Mono) (Hold 1/4" Mono), Class-compliant USB 2.0 type B
- Supported Operating Systems: Windows 7 or higher, Mac OS X 10.10 or higher
